Sensor De Presión
Elemento que transforma la magnitud física de presión en otra magnitud eléctrica
Rangos De Medida
Milésimas de bar hasta los miles de bar
Mide diferentes tipos de presión.
• Presión absoluta • Presión positiva • Presión negativa • Presión Atmosférica
La presión es la magnitud escalar que relaciona la fuerza con la superficie sobre la cual actúa
Detecta Magnitudes fisicas o quimicas
• Temperatura • Intensidad lumínica • Distancia • Aceleración • Inclinación • Desplazamiento • Presión • Fuerza
Llamadas variables de instrumentación
Se utiliza para medir otras variables como:
• Aceite • Altitud • Líquido / flujo de gas • Nivel de agua • Velocidad
Tipos de sensores.
Mecánicos
• Diafragma • Elemento en espiral • Fuelle • Tubo Bourdon
Neumáticos
Sistema tobera-obturador
Electrónicos y electromecánicos
• Resistivos • Magnéticos • De inductancia variable • De inductancia variable con imán • Capacitivos
