Arduino ATMega 328
  1. Plataforma Electronica Abierta
    1. software y software flexible
      1. Microcontrolador y pines
        1. IN/OUT
          1. Sensores y actuadores
            1. Comunicacion con el exterior
              1. Analogas / digitales
          2. Programacion
            1. Editor/Compilador
              1. Bloque de inclusión de módulos
                1. declaración de variables
                  1. bloque de configuración void
                    1. bloque de ejecución continua
                    2. lenguaje de programación Arduino
                    3. pines
                      1. AREF/ referencia analoga
                        1. GND/ tierra
                          1. Pines Digitales 2-13
                            1. Entrada y salida del puerto serie
                              1. Reset
                                1. Pines Analogicos 0-5
                                  1. Fuente alimentacion/5v
                                  2. especificaciones
                                    1. Memoria Flash 16kb
                                      1. SRAM 1KB
                                        1. EEPROM 512 Kbytes
                                          1. F.Reloj/ 16 MHz
