IMPRESORA LASER

COMPONENTES
1. FUSOR
  1. Mecanico
2. Pad o almoadilla se paradora de hoja
  1. Mecanico
3. Pick up roller
  1. Mecanico
4. Unidad de toma de papel
  1. Mecanico
5. Unidad laser
  1. Electronico
6. Placa logica(formatter)
  1. Electronica
7. Tranfer roller
  1. Mecanico
8. Undad de salida
  1. Mecanico
9. Fuente de alto y bajo poder
  1. Electronico
Controlador
1. Placa controladora DC
