NORMAS TECNICAS COLOMBIANAS DE DIBUJO TECNICO
NTC 1914: ROTULADO
CARACTERISTICAS
DE TODO DIBUJO TECNICO
DEBEN TENER CUADRO DE TITULOS
EL CUADRO DE TUTULOS DEBE CONSISTIR EN UNA O MA SIMAGENES
LA INFORMACION DEBE AGRUPARSE EN
ZONA DE IDENTIFICACION
ZONA DE INFORMACION ADICIONAL
NTC 1580: ESCALAS
CARACTERISTICAS
ESCALA DE AMPLIACION
MAYOR DE 1:1
ESCALA NATURAL
RELACION 1:1
ESCALA
RELACION EN LA DIMENSION LINEAL
DE UN ELEMENTO
UN OBJETO
ESCALA DE REDUCCION
MENOR DE 1:1
NTC 1594: TERMINOLOGIA, NTC 1580: ESCALAS, NTC 1687: FORMATO Y PLEGADO, NTC 1914: ROTULADO, NTC 2527 Y NTC 2528: ESCRITURA
