Analyst on H2O! Compleate
1 intro
1.1 Tests conducted
1.1.1 ensure safe to drink!
1.1.2 Thames conducts over 500, 000 tests per year to ensure safe drinking water for the people of London!
1.1.3 DEFRA: Department for Environment Food & Rural Affairs Responsible for drinking water safety
1.1.4 over50 tests conducted
1.1.5 taken from various locatuions Household Rivers outflow from waste centers
2 Drinking water inspectorate
2.1 into three parts
2.1.1 operations Responding to complaints by customers about drinking water quality Regulation of water company Sampling and analyst of H2O assessment of incidents potentially affecting drinking water quality
2.1.2 Regulations Input/advise on new regulations on drinking water Input into Ofwat periodic review of water prices Ofwat- economic regulators of England and wales
2.1.3 Science and Strategy leads reserch and reports back to defra works within corperate and public bodies and reports findings
3 Tests
3.1 50 conducted
3.1.1 Microbiological E.coli, Coliforms
3.1.2 chemical Copper, Cyanide, nitrate, Alpha and beta activity
3.2 ph, Colour, turbidity, taste and odour
4 where does pollutants come from?
4.1 Costal
4.1.1 pollutants in water or sediments oil leaks BP oil spill in gulph of Mexico 2010 Shipping Spillage dumping used fuel? Radioactivity Dalgehty bay
4.2 River
4.2.1 run off from farms excess fertiliser pesticides, herbacides Waste from animals being leached Amonia scilage pits Soil acidification due to crops
4.2.2 Homes Sewage-raw overspill or partial septic tanks not working/damaged or not being emptied chemicals from cleaning homes and peple
4.2.3 recration Paddlers,fishermen
4.3 underground water
4.3.1 boarholes
4.3.2 nutrients leaching
4.4 Base conditions+bank conditions=contact time
5 Objectives of sampling
5.1 baseline monitering
5.1.1 Understand the site, What's happening Vip for development
5.1.2 Impacts in + or- way Sewage treatment works
5.2 environmental indicator
5.2.1 investigate what's happening in the environemt
5.2.2 gives general indication of the health of the area. Mayfly nimph can indicate healthy water area Blood work indicates a poluted stream area Using indicator species
5.3 investigative
5.3.1 industry specific
5.3.2 used after an event fish death find out why and what has happened in order to rectifif the situation. Used to trace back to what has cused the event
5.4 compliance check monitering
5.4.1 Thmes water check the water and have to report the data
5.4.2 Sepa check the summer bathing waters to ensure puplic safty 46 (55%) were classified as being of guideline quality for EU compliance. 36 (43%) were classified as being of mandatory quality for EU compliance. 2 (2%) were classified as failing the mandatory quality for EU compliance Sepa,, 2014
5.5 Reasurance.
5.5.1 of public that i is safe, to drink to swim
6 Representive
6.1 of area
6.2 of stream
7 sampling schemes
7.1 Process
7.1.1 judgment use understanding to track back
7.1.2 stratified
7.1.3 systematic
7.1.4 Random
7.2 Why
7.2.1 how
7.2.2 how to store what are you testing for? chemicals bacteria Alge dark bottle or light, light will allow to photosynthesis and therefore could be dead by the time you check sample . whould show a decrease in oxygen Drak will alow to metals metals might be absorbed by thr bottles. No longer in sample and get incorrect readings.
7.3 WHO
7.3.1 Time recommend samples return to the lab within 2hours to gain most accurate results up to 6 is acceptable 24hrs is a maximum
8 changes in concentration
8.1 heavy rain evet
8.2 Lack of rain
8.3 field run off
8.5 mesurments
8.5.1 Base conditions + bank conditions=contact time
9 Flow gauging
9.1 Flow rating curve
9.1.2 Allows measurement of depth of flow (stage) to be converted to discharge (Q) Discharge is the amount of water flowing.mesured in cumecs Stage=hight of flow
10 how doing
10.1 physical sampling
10.1.1 people, potentially expensive- human error
10.2 automatic sampling
10.2.1 expensive machinery
10.2.2 takes samples automatically and can transmit or store data collected
11 measurement s
11.1 common
11.1.1 pH
11.1.2 EC Electrical conductivity higher results shows higher nutrient levels due to dissolved nutrients (+or- charged)
11.1.3 colomotry colour and cloudyness
11.1.4 Anions alkalies and salts
11.1.5 cations metals
11.2 specific to area
11.2.1 pathogens
12 Good data
12.1 errors
12.1.1 Gross carelessness majorly affect experiment spillage, miss-labelling, incorrect dilution
12.1.2 systematic incorrect calibration of equipment affection of one sample mistakes in data analyst.
12.1.3 random small fulminations in individual results misreading a scale, unpredictable in occurace
12.2 precision
12.2.1 Allow for errors Coefficient variation. CV CV=100(SD/mean) How close repeated measurements on the same sample are, a measure of random error
12.3 Accuracy
12.3.1 Expressed through CV
12.3.2 Closeness of measured value to “true” value, a measure of systematic error
12.3.3 Standard reference materials: independent source, value certified
12.3.4 %Recovery = (Analytical value/truce value) x100
