UA | Flashcards

Question	Answer
Image: a4310f8e-380f-4152-94a4-a6fa460442f7 (image/png)	Normal RBCs
Image: ca79c024-a36b-409c-a3f9-6fe8c0a6d8c9 (image/png)	Microcytic and crenated RBCs
Image: a57449ef-e22e-42b0-9bec-1a5755a6b577 (image/png)	Budding Yeast
Image: 3f2bb965-e6fc-4602-8f67-af18a2eb35d5 (image/png)	Air Bubble
Image: ac8b35bb-f600-4926-bbab-2466e28478ef (image/png)	Squamous epithelial (with oil droplets and NOT RBCs)
Image: 8c0e63df-a447-4786-86ef-c1d58378becb (image/png)	Dysmorphic RBCs
Image: 19a1dc9c-ddc0-465f-b6a7-bdd85ff45dc9 (image/png)	RBCs and one WBC
Image: 8c26a568-3314-434b-8c31-8b38f2e263be (image/png)	WBCs (notice the multi-lobed nuclei)
Image: 445f1592-4df3-4789-be72-820098c7a933 (image/png)	WBC clump
Image: bc2db757-936d-4de2-9c60-9aaeea1dfc85 (image/png)	Eosinophils (Hansel stained)
Image: d797d159-c1de-4d98-8e58-faef22440046 (image/png)	WBCs (with acetic acid nuclear enhancement)
Image: 4f8dfb22-cd37-4122-8de9-a7a069a05c41 (image/png)	Squamous epithelial
Image: e6a9b360-e497-4f28-a3e1-e57e545ea544 (image/png)	Squamous, RTE, WBC, caudate transitional, RBC
Image: b2a7876c-97d1-420a-bf50-4398fb9db6a5 (image/png)	Squamous epithelial and phenazopyridine crystals after refridgeration
Image: f4e50fa1-f30c-45a6-abe2-5325e83081f4 (image/png)	Squamous epithelial (under low power)
Image: 036676aa-3249-4567-ac12-217d937d886f (image/png)	Clump of squamous epithelial cells
Image: 4ee74063-f72f-4963-8443-97a7fdc07cc7 (image/png)	Clump of squamous epithelial cells with folded forms
Image: 410388d9-61eb-47e5-8e6b-d6457fd382e4 (image/png)	Spherical transitional epithelial cells
Image: aec6e4b4-12c2-4f49-b152-10deb35aab04 (image/png)	Caudate transitional epithelial cells
Image: 07add3c1-ac41-404d-bde4-1df3318000f1 (image/png)	Syncytia of transitional epithelial cells
Image: bc93bc63-c4c7-448f-b314-380785e7834b (image/png)	RTE cells. Oval distal convoluted tubule cells (notice the eccentrically placed nuclei).
Image: b8edf821-3bbd-42b6-82a3-ec08d564e4bc (image/png)	RTE cells (cuboidal, from collecting duct)
Image: ecb74968-6e23-40b5-b8a7-05e07bf9a87c (image/png)	RTE cell (proximal convoluted tubule cell with granules and attached fat globules).
Image: 8ace9ed5-b0bb-4b85-ad0b-9c713b1a1cbc (image/png)	Fragment of RTE cells from collecting duct
Image: d4722692-f312-4078-a2fa-d5d8b08a8493 (image/png)	Oval fat body
Image: cbf505f9-65d7-49c7-80dc-b5b999ad930b (image/png)	Oval fat body (sudan III stained)
Image: cea0e0d6-6084-4d80-9c29-f4639d2b5e48 (image/png)	Oval fat body (bright field on right and polarized on left (notice the Maltese cross))
Image: 1f3a0938-cf87-42e9-b007-dfb14dc9c88b (image/png)	Hemosiderin granules
Image: abada83f-4d1b-4cc3-8546-60b8fd19022d (image/png)	Bacteria
Image: 0a6dd651-37d5-41c8-acd4-be4ac30063bb (image/png)	Yeast (mycelial forms)
Image: 1f3de95d-303d-4c7f-8ffc-a928b0e39880 (image/png)	Mucous threads
Image: f648060e-9f03-4ec2-905f-2d6f23d3429d (image/png)	Hyaline casts
Image: c32680e8-8c23-4105-8fea-120d2c2c887e (image/png)	Hyaline cast (under phase microscopy)
Image: 0640fbf1-70f6-4f5a-8a52-8ab0f710506c (image/png)	Convoluted hyaline cast
Image: 21928f19-2826-4dc7-9543-27c0cca10071 (image/png)	Hyaline cast (top - with amorphous urates and bottom - attached to mucus pseudocast)
Image: e3315d04-7700-49b5-8413-2efbfc85a7b0 (image/png)	Hyaline cast
Image: 7462b420-37ce-422a-b14f-bff5b16c4e76 (image/png)	Hyaline cast containing the occasional granules
Image: 62013620-6f44-4dd0-ae21-4b30ca5073c1 (image/png)	RBC cast
Image: d4fd9ac2-437c-4dd3-bb3d-2a1b484bbd95 (image/png)	Disintegrating RBC cast (notice the presence of free RBCs)
Image: 8bbb9601-d283-42cb-b7a8-0bbd8b220505 (image/png)	RBC cast (under phase microscopy)
Image: 28b8cb8d-f59d-4a73-820f-cabd915e4787 (image/png)	Cast containing hemoglobin (also RBCs and yeast are present)
Image: fc86aa43-b7b4-49ae-8d20-8866052349f2 (image/png)	Granular dirty brown cast
Image: c77d7e77-b63b-44a9-88d2-c737b4b96da8 (image/png)	WBC cast
Image: 5c874416-6ff4-4c1b-b3be-230fefbe16b8 (image/png)	Disintegrating WBC cast
Image: b391dfe8-620b-4cec-97b7-4b6b941db8da (image/png)	WBC clump (notice the absence of a cast matrix)
Image: a9163e5d-a809-48b5-88d3-5f0be68074aa (image/png)	RTE cell cast
Image: 1f11096c-7f1e-4c59-b03f-b55000678e49 (image/png)	RTE cell cast
Image: d76e324f-8086-4a1f-96ed-a67fa0c66c7a (image/png)	RTE cell cast
Image: 1c69fced-3fc6-4df7-afc7-6680d4426af8 (image/png)	Fatty cast showing adherence of fat droplets to cast matrix
Image: a6558e94-7eb2-497c-a6f3-6520cd344d2f (image/png)	RTE cast with bilirubin stained cells
Image: 90ec13a6-3eef-4bd4-89cb-d4bf8eef9aff (image/png)	Fatty cast
Image: d152af33-b0a0-41a5-a26f-4b1388eab39e (image/png)	Finely granular cast and uric acid crystals
Image: 305b7c9a-3a8a-484c-b550-516824938892 (image/png)	Granular cast formed at a tubular bend
Image: b56b9236-4e47-4453-b9bb-2ff94e92b07d (image/png)	Granular disitenigrating cellular cast
Image: 3df1570e-51a8-4c33-8b2f-5dced6ccd3fd (image/png)	Fatty cast under phase micriscopy
Image: d9f179ba-6fb0-44b2-b33b-3a82b81f05ee (image/png)	Coarsely granular cast, squamous epithelial cell, and mucous
Image: 04d94bf7-a368-42fd-b396-638466cb8bfc (image/png)	Waxy casts
Image: cbf39b7c-bea0-4a8d-bd66-9a443baf4190 (image/png)	Granular cast degenerating into waxy cast
Image: 338c38d8-c28e-4234-bb94-2a84ea2a44ad (image/png)	Waxy cast
Image: 440513b8-4cc5-4c7d-aa3c-cefcbc1030e3 (image/png)	Waxy cast
Image: d6c07f7a-0091-4c85-b5d3-64a4e8595517 (image/png)	Broad granular cast becoming waxy
Image: 40291fe5-9d35-4247-b995-a1e65cb3e0ab (image/png)	Broad waxy cast
Image: 1c9342b7-86d7-43b4-b353-13e368af4f70 (image/png)	Broad bile stained waxy cast
Image: f1c783e8-d12c-41f4-aa17-7903de676213 (image/png)	Amorphous urates
Image: c2006134-3c5b-4449-a713-66ee176b08b7 (image/png)	Uric acid cryststals
Image: 541e4d4e-63d5-4aa5-ad56-366be310ae1e (image/png)	Uric acid crytals
Image: 41e75312-6a0f-4739-9ed3-86744c9ae5d6 (image/png)	Uric acid crystals under polarized light
Image: 57077fff-9f36-4a62-882f-d80d044460cf (image/png)	Clumps of uric acid crystals ( notice the whetstone, not the hexagonal shape that differentiates uric acid crystals from cysteine crystals)
Image: 059d1136-38d3-423c-a8f7-4f31cce47b47 (image/png)	Dihydrate calcium oxalate crystals
Image: 67575030-939b-4f09-963d-6adff762414d (image/png)	Dihydrate calcium oxalate crystals under phase microscopy
Image: a7f92d63-7beb-4324-bc76-3f4c09ff29ee (image/png)	Amorphous phosphates
Image: d901a2a2-561b-4eb7-91d7-ee1f6a719c5c (image/png)	Triple phosphate crystal
Image: dd7f1e57-1901-4751-988d-49b20fffd2da (image/png)	"coffin lid" and other forms of triple phosphate crystals
Image: 3b7858e3-0c7a-4521-896f-6c9f44567057 (image/png)	monohydrate calcium oxalate crystals
Image: c4652971-77eb-45bb-b767-05e27506a0c0 (image/png)	triple phosphate crystal sand amorphous phosphates
Image: b1394bcd-db31-49fb-942f-dc7edc193ef2 (image/png)	Ammonium biurate crystals
Image: fe84caca-7222-4312-b09c-39520bdf74c4 (image/png)	Calcium carbonate crystals
Image: 05089f29-d22c-458b-be3f-b60352374aa5 (image/png)	Cystine crystals
Image: ce9f4023-c43e-40a0-a731-904696434cd9 (image/png)	Clump of cystine crystals
Image: eef49892-55c0-4337-ae15-c120f6eba43a (image/png)	Cholesterol crystals
Image: 2ea6cf5b-109a-45c8-b4e0-dc76b5edd852 (image/png)	Tyrosine crystal sin fine needle clumps
Image: b14949c3-3787-4cd8-a4e8-0cb01686102c (image/png)	Tyrosine crystals in rosette form
Image: c622f1c0-0fb7-44d8-b045-2be2cc9592c7 (image/png)	Leucine crystals
Image: 30b61f55-bf1f-492f-a71b-4fc27b687a2b (image/png)	Cholesterol crystals under polarized light
Image: 241343d5-f41b-4c09-859b-29c8d44bd649 (image/png)	Bilirubin crystals ( notice the bright yellow color)
Image: 9f17ea31-bd81-43a6-985f-c0deae7cf8ac (image/png)	Ampicillin crystals, non refrigerated
Image: 670da8f5-de72-4ccc-b1f6-3d3c2fad4587 (image/png)	Sulfa crystals and bacteria seen in UTI
Image: 4fff9e8b-17ec-4728-ab12-d31e551a1470 (image/png)	Ampicilan crystals after refridgeration
Image: a73c5b39-84e3-414a-a7af-69c63050d9b1 (image/png)	Sulfa crystals in rossette form
Image: 234a6511-7d9f-4e3a-9af6-70677c8e4093 (image/png)	Starch granules ( notice the dimpled center)
Image: 7a225777-c687-47e0-b267-3292eaaa03bd (image/png)	Pollen granule ( notice the concentric circles)
Image: b2056d9b-9b1d-4d97-aeab-c8e8c3ed6afe (image/png)	Fiber resembling a cast
Image: 724e8470-6cd8-44f8-8db6-f62b080a0aa8 (image/png)	Fecal material and oil artifacts
Image: 1e34a7fb-1749-4ca6-9432-575f8c9ebac4 (image/png)	Vegetable fiber resembling a waxy cast

Image: a4310f8e-380f-4152-94a4-a6fa460442f7 (image/png)

Normal RBCs

Image: ca79c024-a36b-409c-a3f9-6fe8c0a6d8c9 (image/png)

Microcytic and crenated RBCs

Image: a57449ef-e22e-42b0-9bec-1a5755a6b577 (image/png)

Budding Yeast

Image: 3f2bb965-e6fc-4602-8f67-af18a2eb35d5 (image/png)

Air Bubble

Image: ac8b35bb-f600-4926-bbab-2466e28478ef (image/png)

Squamous epithelial (with oil droplets and NOT RBCs)

Image: 8c0e63df-a447-4786-86ef-c1d58378becb (image/png)

Dysmorphic RBCs

Image: 19a1dc9c-ddc0-465f-b6a7-bdd85ff45dc9 (image/png)

RBCs and one WBC

Image: 8c26a568-3314-434b-8c31-8b38f2e263be (image/png)

WBCs (notice the multi-lobed nuclei)

Image: 445f1592-4df3-4789-be72-820098c7a933 (image/png)

WBC clump

Image: bc2db757-936d-4de2-9c60-9aaeea1dfc85 (image/png)

Eosinophils (Hansel stained)

Image: d797d159-c1de-4d98-8e58-faef22440046 (image/png)

WBCs (with acetic acid nuclear enhancement)

Image: 4f8dfb22-cd37-4122-8de9-a7a069a05c41 (image/png)

Squamous epithelial

Image: e6a9b360-e497-4f28-a3e1-e57e545ea544 (image/png)

Squamous, RTE, WBC, caudate transitional, RBC

Image: b2a7876c-97d1-420a-bf50-4398fb9db6a5 (image/png)

Squamous epithelial and phenazopyridine crystals after refridgeration

Image: f4e50fa1-f30c-45a6-abe2-5325e83081f4 (image/png)

Squamous epithelial (under low power)

Image: 036676aa-3249-4567-ac12-217d937d886f (image/png)

Clump of squamous epithelial cells

Image: 4ee74063-f72f-4963-8443-97a7fdc07cc7 (image/png)

Clump of squamous epithelial cells with folded forms

Image: 410388d9-61eb-47e5-8e6b-d6457fd382e4 (image/png)

Spherical transitional epithelial cells

Image: aec6e4b4-12c2-4f49-b152-10deb35aab04 (image/png)

Caudate transitional epithelial cells

Image: 07add3c1-ac41-404d-bde4-1df3318000f1 (image/png)

Syncytia of transitional epithelial cells

Image: bc93bc63-c4c7-448f-b314-380785e7834b (image/png)

RTE cells. Oval distal convoluted tubule cells (notice the eccentrically placed nuclei).

Image: b8edf821-3bbd-42b6-82a3-ec08d564e4bc (image/png)

RTE cells (cuboidal, from collecting duct)

Image: ecb74968-6e23-40b5-b8a7-05e07bf9a87c (image/png)

RTE cell (proximal convoluted tubule cell with granules and attached fat globules).

Image: 8ace9ed5-b0bb-4b85-ad0b-9c713b1a1cbc (image/png)

Fragment of RTE cells from collecting duct

Image: d4722692-f312-4078-a2fa-d5d8b08a8493 (image/png)

Oval fat body

Image: cbf505f9-65d7-49c7-80dc-b5b999ad930b (image/png)

Oval fat body (sudan III stained)

Image: cea0e0d6-6084-4d80-9c29-f4639d2b5e48 (image/png)

Oval fat body (bright field on right and polarized on left (notice the Maltese cross))

Image: 1f3a0938-cf87-42e9-b007-dfb14dc9c88b (image/png)

Hemosiderin granules

Image: abada83f-4d1b-4cc3-8546-60b8fd19022d (image/png)

Bacteria

Image: 0a6dd651-37d5-41c8-acd4-be4ac30063bb (image/png)

Yeast (mycelial forms)

Image: 1f3de95d-303d-4c7f-8ffc-a928b0e39880 (image/png)

Mucous threads

Image: f648060e-9f03-4ec2-905f-2d6f23d3429d (image/png)

Hyaline casts

Image: c32680e8-8c23-4105-8fea-120d2c2c887e (image/png)

Hyaline cast (under phase microscopy)

Image: 0640fbf1-70f6-4f5a-8a52-8ab0f710506c (image/png)

Convoluted hyaline cast

Image: 21928f19-2826-4dc7-9543-27c0cca10071 (image/png)

Hyaline cast (top - with amorphous urates and bottom - attached to mucus pseudocast)

Image: e3315d04-7700-49b5-8413-2efbfc85a7b0 (image/png)

Hyaline cast

Image: 7462b420-37ce-422a-b14f-bff5b16c4e76 (image/png)

Hyaline cast containing the occasional granules

Image: 62013620-6f44-4dd0-ae21-4b30ca5073c1 (image/png)

RBC cast

Image: d4fd9ac2-437c-4dd3-bb3d-2a1b484bbd95 (image/png)

Disintegrating RBC cast (notice the presence of free RBCs)

Image: 8bbb9601-d283-42cb-b7a8-0bbd8b220505 (image/png)

RBC cast (under phase microscopy)

Image: 28b8cb8d-f59d-4a73-820f-cabd915e4787 (image/png)

Cast containing hemoglobin (also RBCs and yeast are present)

Image: fc86aa43-b7b4-49ae-8d20-8866052349f2 (image/png)

Granular dirty brown cast

Image: c77d7e77-b63b-44a9-88d2-c737b4b96da8 (image/png)

WBC cast

Image: 5c874416-6ff4-4c1b-b3be-230fefbe16b8 (image/png)

Disintegrating WBC cast

Image: b391dfe8-620b-4cec-97b7-4b6b941db8da (image/png)

WBC clump (notice the absence of a cast matrix)

Image: a9163e5d-a809-48b5-88d3-5f0be68074aa (image/png)

RTE cell cast

Image: 1f11096c-7f1e-4c59-b03f-b55000678e49 (image/png)

RTE cell cast

Image: d76e324f-8086-4a1f-96ed-a67fa0c66c7a (image/png)

RTE cell cast

Image: 1c69fced-3fc6-4df7-afc7-6680d4426af8 (image/png)

Fatty cast showing adherence of fat droplets to cast matrix

Image: a6558e94-7eb2-497c-a6f3-6520cd344d2f (image/png)

RTE cast with bilirubin stained cells

Image: 90ec13a6-3eef-4bd4-89cb-d4bf8eef9aff (image/png)

Fatty cast

Image: d152af33-b0a0-41a5-a26f-4b1388eab39e (image/png)

Finely granular cast and uric acid crystals

Image: 305b7c9a-3a8a-484c-b550-516824938892 (image/png)

Granular cast formed at a tubular bend

Image: b56b9236-4e47-4453-b9bb-2ff94e92b07d (image/png)

Granular disitenigrating cellular cast

Image: 3df1570e-51a8-4c33-8b2f-5dced6ccd3fd (image/png)

Fatty cast under phase micriscopy

Image: d9f179ba-6fb0-44b2-b33b-3a82b81f05ee (image/png)

Coarsely granular cast, squamous epithelial cell, and mucous

Image: 04d94bf7-a368-42fd-b396-638466cb8bfc (image/png)

Waxy casts

Image: cbf39b7c-bea0-4a8d-bd66-9a443baf4190 (image/png)

Granular cast degenerating into waxy cast

Image: 338c38d8-c28e-4234-bb94-2a84ea2a44ad (image/png)

Waxy cast

Image: 440513b8-4cc5-4c7d-aa3c-cefcbc1030e3 (image/png)

Waxy cast

Image: d6c07f7a-0091-4c85-b5d3-64a4e8595517 (image/png)

Broad granular cast becoming waxy

Image: 40291fe5-9d35-4247-b995-a1e65cb3e0ab (image/png)

Broad waxy cast

Image: 1c9342b7-86d7-43b4-b353-13e368af4f70 (image/png)

Broad bile stained waxy cast

Image: f1c783e8-d12c-41f4-aa17-7903de676213 (image/png)

Amorphous urates

Image: c2006134-3c5b-4449-a713-66ee176b08b7 (image/png)

Uric acid cryststals

Image: 541e4d4e-63d5-4aa5-ad56-366be310ae1e (image/png)

Uric acid crytals

Image: 41e75312-6a0f-4739-9ed3-86744c9ae5d6 (image/png)

Uric acid crystals under polarized light

Image: 57077fff-9f36-4a62-882f-d80d044460cf (image/png)

Clumps of uric acid crystals ( notice the whetstone, not the hexagonal shape that differentiates uric acid crystals from cysteine crystals)

Image: 059d1136-38d3-423c-a8f7-4f31cce47b47 (image/png)

Dihydrate calcium oxalate crystals

Image: 67575030-939b-4f09-963d-6adff762414d (image/png)

Dihydrate calcium oxalate crystals under phase microscopy

Image: a7f92d63-7beb-4324-bc76-3f4c09ff29ee (image/png)

Amorphous phosphates

Image: d901a2a2-561b-4eb7-91d7-ee1f6a719c5c (image/png)

Triple phosphate crystal

Image: dd7f1e57-1901-4751-988d-49b20fffd2da (image/png)

"coffin lid" and other forms of triple phosphate crystals

Image: 3b7858e3-0c7a-4521-896f-6c9f44567057 (image/png)

monohydrate calcium oxalate crystals

Image: c4652971-77eb-45bb-b767-05e27506a0c0 (image/png)

triple phosphate crystal sand amorphous phosphates

Image: b1394bcd-db31-49fb-942f-dc7edc193ef2 (image/png)

Ammonium biurate crystals

Image: fe84caca-7222-4312-b09c-39520bdf74c4 (image/png)

Calcium carbonate crystals

Image: 05089f29-d22c-458b-be3f-b60352374aa5 (image/png)

Cystine crystals

Image: ce9f4023-c43e-40a0-a731-904696434cd9 (image/png)

Clump of cystine crystals

Image: eef49892-55c0-4337-ae15-c120f6eba43a (image/png)

Cholesterol crystals

Image: 2ea6cf5b-109a-45c8-b4e0-dc76b5edd852 (image/png)

Tyrosine crystal sin fine needle clumps

Image: b14949c3-3787-4cd8-a4e8-0cb01686102c (image/png)

Tyrosine crystals in rosette form

Image: c622f1c0-0fb7-44d8-b045-2be2cc9592c7 (image/png)

Leucine crystals

Image: 30b61f55-bf1f-492f-a71b-4fc27b687a2b (image/png)

Cholesterol crystals under polarized light

Image: 241343d5-f41b-4c09-859b-29c8d44bd649 (image/png)

Bilirubin crystals ( notice the bright yellow color)

Image: 9f17ea31-bd81-43a6-985f-c0deae7cf8ac (image/png)

Ampicillin crystals, non refrigerated

Image: 670da8f5-de72-4ccc-b1f6-3d3c2fad4587 (image/png)

Sulfa crystals and bacteria seen in UTI

Image: 4fff9e8b-17ec-4728-ab12-d31e551a1470 (image/png)

Ampicilan crystals after refridgeration

Image: a73c5b39-84e3-414a-a7af-69c63050d9b1 (image/png)

Sulfa crystals in rossette form

Image: 234a6511-7d9f-4e3a-9af6-70677c8e4093 (image/png)

Starch granules ( notice the dimpled center)

Image: 7a225777-c687-47e0-b267-3292eaaa03bd (image/png)

Pollen granule ( notice the concentric circles)

Image: b2056d9b-9b1d-4d97-aeab-c8e8c3ed6afe (image/png)

Fiber resembling a cast

Image: 724e8470-6cd8-44f8-8db6-f62b080a0aa8 (image/png)

Fecal material and oil artifacts

Image: 1e34a7fb-1749-4ca6-9432-575f8c9ebac4 (image/png)

Vegetable fiber resembling a waxy cast

Next up

UA

Description

Resource summary

Similar

	Created by Fritz Hull about 8 years ago
